Graphtec CE8000-130 Desktop Cutting Plotter (1300mm/54 inch) with Stand

Price: £3,899.00 + VAT

Graphtec CE8000-130 is a desktop 1300mm wide (54 inch), roll fed cutting plotter for making signs, decals, and labels, as well as heat transfer graphics for garments and custom-made merchandise.

3 Years Lease

5 Years Lease

Description

Graphtec CE8000-130 is a 1300mm wide (54 inch), roll fed cutting plotter featuring fast cutting speeds and compatibility with a variety of both thin and thicker media.

Ease of use, an optical print and cut detection system,and the ability to cut multiple pre-printed graphics without user input make the Graphtec CE8000 Series ready for perfect teamwork with any printer.

The Graphtec CE8000 Series cutting plotters include Cutting Master 5, a plug-in software for Adobe Illustrator and CorelDRAW, Graphtec Studio 2 (for Windows) and Graphic Studio (for Mac) software, easy to use software for creating original designs and a Windows Driver.

Design Supply, a Graphtec Authorised Reseller, works closely with Graphtec to provide the best solutions available to get the job done for your business and maximise your opportunities.

With more than 35 years of experience in the large format market, Design Supply offers expertise and knowledge in tailoring the exact solution for your specific application.

Key features

The Graphtec CE8000-130 Cutting Plotter  is an easy to use, versatile, high quality, entry level desktop Cutting Plotter.

  • Ideal for users based in a smaller work space, the Graphtec CE8000-60 Cutting Plotter automatically cuts a wide variety of media up to 1300mm/54 inches wide
  • Easy to use for print and cut applications, the Graphtec CE8000-130 Cutting Plotter features Advanced Registration Mark Sensing (ARMS 8.0) system
  • ARMS is a  registration mark sensor for print and cut jobs , which reads registration marks and accurately contour cuts designs that are output from any printer
  • A datalink barcode system, generates barcodes as part of the design, which enables hands free operation
  • Designs are then read by the CE8000-130, which automatically loads cutting information and processes print and cut jobs
  • The Graphtec CE8000-130 is versatile, ideal for a wide variety of cutting applications including sticker and decal creation, window signage, window tint films, heat transfer apparel
  • The CE8000-130 is the best cutter for Self-Adhesive Vinyls, HTV Materials, Paper, Card and Stencil Materials

Specifications

Max cutting speed 1000mm per second
Max acceleration 14.1m/s²
Max cutting force 450g
Max cutting area 1270mm x 50m
Media width 85mm to 1372mm/54inch
Min character size 5mm
Mechanical resolution 0.005mm
Max media thickness 0.25mm
Buffer memory 2MB
Registration marks ARMS 8.0 optical sensor for print and cut
Software Cutting Master 5 (Illustrator/CorelDRAW plug-in), Graphtec Studio

What's in the box

In the box

  • Graphtec CE8000-130  Desktop Cutting Plotter, 1300mm wide
  • Stand
  • Roll Feeder:
  • Loupe (PM-CT-001)
  • Cutting Blade 0.9mm Supersteel: (CB09UB-P)
  • Blade Holder: 0.9mm (PHP-33-CB09N-HS)
  • Cutter plunger (PHP33-09N-HS)
  • USB Cable (2.9 m long)
  • Power Cord
  • Safety Guide
  • Setup Manual

With your order

  • Manufacturer warranty (options to extend available)
  • Delivery, installation and training: ask our team

Options and consumables

Item Part code
Cutting Media Table for 400mm & 600mm OPH-A45
Media Catch Baskets PGO111
Roll Media Stocker: OPH-A57</p> Ask us
Media Flange Kit Ask us
Additional Push Roller Kit Ask us
Water-based Fiber-tipped Pen (KF700 Series Fiber tip) Ask us
Fiber-tipped Pen Holder (PHP31-FIBER) Ask us
Graphtec 0.9mm Supersteel Blade 45°angle CB09UB
Graphtec 0.9mm Supersteel Blades 45°angle(5) (for PVC film) CB09UB-5
Graphtec 0.9mm Supersteel Blades for Car- Ask us
film, 60°angle(5) (for PPF) CB09UB-K60-5
Graphtec 1.5mm Blade for paper/cardboard, 45°angle(5) CB15U-5
Graphtec 1.5mm Blade for paper/cardboard, 30°angle(5) CB15U-K30-5
Loupe PM-CT-001
Fiber-tip pen holder PHP31-FIBER
Black Water-based fiber-tip pen(10 pens): KF700-BK</p> Ask us
Red Water-based fiber-tip pen(10 pens) KF700-RD
Ballpoint pen holder for KB700 pen PHP34-BALL
Black Oil-based ballpoint pen(10) KB700-BK
USB cable: (PM-ET-001) Ask us
</div> Ask us

Data sheets

Graphtec CE8000-40, 60, 130 Series Brochure

<p><div id=”TMPwmHiddenDiv”>

=”TMPwmHiddenDiv” class=”yoast-text-mark”>>

<div id=”TMPwmHiddenDiv”>

<div id=”TMPwmHiddenDiv”>

d=”TMPwmHiddenDiv”>
d=”TMPwmHiddenDiv”>

 </div>

Manufacturer information

The Graphtec CE8000-130 is part of Graphtec’s range of cutting plotters.

Design Supply can supply, install and support it, and extend the warranty if you need longer cover.
