HP Latex 335 (64 inch /1.63m) Large Format Printer


The HP Latex 335 Printer provides affordable access to indoor and outdoor 64-inch/1.63m printing, unrivalled versatility and healthier printing with water based HP Latex Inks. The HP Latex 335 is ideal for entry to outdoor and indoor signage and prints and an environmentally-minded solution to replace solvent-based technology. The HP Latex 335 Printer features automatic, fast, reliable low-maintenance printing on a wide range of media from vinyl, textiles, paper, film, wall paper to low-cost uncoated options. HP Latex 335 Printer includes a take up reel and is available as a stand-alone printer, and as a Print & Cut Solution and works with 775ml cartridges.

With 100’s of media available, expand your services to the growing temporary textiles, vehicle graphics, and wall covering markets and produce great results whether printing point of purchase posters, outdoor and event banners, vehicle wraps and graphics, backlit applications, wall coverings and canvas. Or replace your current solvent printer with the environmentally friendly HP Latex solutions.

At Design Supply, an HP Authorised Partner and DesignJet Specialist, we work closely with HP to provide the best solutions available to get the job done for your business and maximise your opportunities. With over 30 years of experience in the large format printer market, we offer expertise and knowledge in tailoring the exact solution for your specific application.


HP Latex 300 Printer Series

HP Latex Print and Cut Solutions: 115,315,335

HP Latex Print and Cut

HP Wall Art

HP Latex Canvas Possibilities

How to mount a Canvas

Ontario Museum

Unique Frescos restored

HP Latex: Wallpaper company


Print more applications and reach indoor spaces that solvent solutions can’t with the new HP Latex 335 Printer. Best in class based on productivity and environmental advantages compared to the leading and comparably priced solvent-technology based printers, the HP Latex 335 Printer features easy maintenance and operation.

The HP Latex 335 Printer features an accessible print zone with large windows and lights. HP Latex 335 prints are completely cured and dry inside printer, ready for immediate finishing and delivery. HP Latex inks scratch resistance is comparable to hard-solvent inks on SAV and PVC banner, which means you can consider unlaminated for short-term signage. HP Latex inks have outdoor durability of up to 5 years when laminated, and 3 years when unlaminated.

The HP Latex 335 Printer features HP 831 Latex Printheads which provide 1200 dpi native resolution, producing smooth transitions and fine detail. User-replaceable, HP Latex printheads feature 1200 nozzles per inch with HP’s automatic drop detection and nozzle replacement, reducing maintenance and ensuring colour consistency. Print panels or tiles with excellent colour consistency for an edge-to-edge match. Keep day-one image quality by replacing the printheads yourself in a few minutes, without a service call.

The HP Latex 335 Printer works with HP 831 Latex ink cartridges which are available in 775 ml. Additionally, the HP Latex 335 uses HP Latex Optimizer, which interacts with HP Latex Inks to rapidly immobilize pigments on the surface of the print and achieves high image quality at high productivity. HP Latex 335 features HP Quick Substrate Profiling, a simplified colour management library available directly from the front panel using the 4-inch touchscreen or online. HP Quick Substrate Profiling includes a full set of on-board generic and specific HP substrate profiles and access to an online substrate profile library of over 250 custom profiles and the ability to fine tune, edit, clone and remove profiles.

The HP Latex 335 Printer includes an automatic cutter, which cuts efficiently and delivers jobs immediately with the automatic X-axis cutter, which can be used on vinyl, paper-based media, and backlit polyester film.

Enjoy all the benefits of HP Latex printing technology, including scratch resistant prints, ideal for short term applications (and avoiding lamination) saving time and money. High quality prints at high printing speeds, means jobs can be delivered in the same day. HP Latex Technology delivers all the certifications that matter to your operators, your business and the environment. Using water-based inks eliminates exposure to inks with hazard warning labels and high solvent concentrations, and simplifies ventilation, storage and transportation requirements. HP Latex Inks enable more differentiation, as odourless prints go where solvent can’t. HP is designing end-to-end sustainability into large-format printing. The Latex 335 Printer is EPEAT Bronze registered, a designation for reduced environmental impact.


The HP Latex 335 Printer produces up to 1200 x 1200 dpi resolution with HP double swath technology and has a maximum print speed of 48m2/hr. Indoor quality prints as 12m2/hr and outdoor quality prints at 16m2/hr. The HP Latex 335 Printer’s suggested monthly volume printing is less than 250m2/month. The following are print speeds based on user-selected print modes and four or 6 colours.

Print Mode (bidirectional) m2/hr ft<sup)2/hr
Billboard (2 pass) 50 538
Outdoor High Speed (4 pass) 23 248
Outdoor Plus (6 pass) 17 183
Indoor Quality (8 pass) 13 140
Indoor High Quality (10 pass) 10 108
Backlits, Textiles, Canvases (16 pass) 6 65
High Saturation Textiles (20 pass) 5 54

The HP Latex 335 Printer features front-media loading capabilities and accepts a media roll of up to a maximum roll weight of 42 kg and a media thickness of up to19.7 mil. The HP Latex 335 Printer features new HP Optical Media Advance Sensor (OMAS) which delivers precise and accurate motion control of media advance between print swaths. The HP Latex 335 Printer includes a take up reel for unattended printing. The HP Latex 335 Printer can be unplugged without damage to the printhead.

Free software available for the HP Latex 335 Printer includes HP Latex Mobile app, which allows you to stay connected with HP Latex 335 when you’re away, HP Signage Suite and HP WallArt Suite, which allow you to bring your ideas to life. HP Wall Art is free, cloud-based software designed to use with HP Latex Printers. Voted in 2013, the “Best Special Application Solution” by the European Digital Press Awards. HP Wall Art features design, 3D visualization, job sharing, automatic PDF printing files, creation of customised installation instructions and developers kit to allow integration into websites.

New, easy remote online operator training, from the basics on how to start operating the printer to tips on how to grow your business with new applications is available. Visit hp.com/communities/HPLatex300.

There are 100’s of different media for the HP Latex 335 Printer, including a broad choice among coated and uncoated papers, self-adhesive vinyls, wallcoverings, PVC-free wallpaper, banner (light display, heavy); fabrics (cotton, eco-cotton, polyester, heat-sensitive polyesters, synthetic leather, silk) canvas, synthetics and many more. Fabrics, mesh textile and any other porous materials require a liner. Choose from a wide range of compatible substrates from industry-leading media providers including specialty substrates, deep embossed, textured or metallic coated media. Our media specialists at Design Supply have the expertise to help you determine the best solutions for your particular printing needs. HP Latex prints feature a flexible ink layer, ideal for conforming to complex surfaces, including vehicle wraps and canvas (everyday satin, premium satin, gesso coated, inkjet coated, gallery wrap). For more information, including the 3M MCS Warranty, ask your Design Supply account manager.

Optional accessories for the HP Latex 335 Printer include additional 64-inch 2-in and 3-in spindles, for quick ready to load multiple media versatility and convenience. The 64-inch single spindles handle up to 42 kg (92.6 lb).

Count on dependable support to create the best image possible from HP and Design Supply. For added peace of mind, HP Latex 335 Printer features a 12-month limited hardware warranty. HP Services offer a broad portfolio of proven support programs to help keep your business running productively including HP Care Pack Services, an extensive portfolio of installation and post warranty on-site support services and preventative maintenance kits and HP Ecosolutions Training for printing companies to help enhance printing and imaging environments and protect your investment and grow your business. Ask us at Design Supply, and we can tailor the best solution possible for your needs.



HP Latex 335 Printer

HP Latex 335 Printer: V7L47A

HP 831 Latex Printheads (6): CZ677A, CZ678A, CZ679A, CZ680A

HP 831 Maintenance cartridge: CZ681A

Printer stand


Take-up reel

Variable front tension kit

User maintenance kit

Edge holders

Quick reference guide

Setup poster

FlexiPrint HP Edition RIP

Documentation software

Power Cords

One year limited hardware warranty


HP Latex 300/500 User Maintenance Kit: F0M59A

HP Latex 64-in Printer 2-in Spindle: FOM56A

HP Latex 64-in Printer 3-in Spindle: FOM58A

Software included:

SAi FlexiPrint HP Edition RIP


HP 831 Cyan/Black Latex Printhead: CZ677A

HP 831 Yellow/Magenta Latex Printhead: CZ678A

HP 831 Light Magenta/Light Cyan Latex Printhead: CZ679A

HP 831 Latex Optimizer Printhead: CZ680A

HP 821 775ml Black Latex Ink Cartridge: CZ694A

HP 821 775ml Cyan Latex Ink Cartridge: CZ695A

HP 821 775ml Magenta Latex Ink Cartridge: CZ696A

HP 821 775ml Yellow Latex Ink Cartridge: CZ697A

HP 821 775ml Light Cyan Latex Ink Cartridge: CZ698A

HP 821 775ml Light Magenta Latex Ink Cartridge: CZ699A

HP 821 775ml Latex Optimizer Ink Cartridge: CZ706A

HP 831 Latex Maintenance Cartridge: CZ681A

HP Media:

HP PVC-free Durable Smooth Wall Paper (REACH, FSC and UL GREENGUARD GOLD Certified)

HP Permanent Gloss Adhesive Vinyl (REACH Compliant)

HP Backlit Polyester Film

HP Premium Poster Paper (FSC Certified)

For a complete list, please speak to your Design Supply account manager

For more information on the 3M MCS Warranty for Certified Graphics Manufacturers, please speak to your Design Supply account manager

Service and support:

HP 3 Year Next Business Day Defective Media Retention: U9JD6E

HP 2 Year Next Business Day Defective Media Retention: U9JD5E

HP 2 Year Post warranty Next Business Day Defective Media Retention: U9JE0PE

HP 1 Year Post Warranty Next Business Day Defective Media Retention: U9JD9PE


HP Latex 335 datasheet

HP Latex 335 Print and Cut Solution datasheet

HP Latex 115 315 335 portfolio datasheet

HP Latex Portfolio comparison datasheet

HP Latex inks and durability brochure

HP Latex Mobile datasheet

HP PrintOS Mobile App datasheet

HP Latex Printing Technology: environmental certifications and eco-labels overview datasheet

HP Graphics Solutions for Photofinishers and Photo Labs brochure

HP Latex Printers and Wall Paper Certifications datasheet

HP Cookbook Durable Textiles brochure

HP Customised Optimisation Services datasheet

HP  JetAdvantage datasheet


HP Latex proprietary technology provides innovation in versatility, flexibility and durability, driving the transformation of the industry and expanding applications to the interior decoration market. Introduced in 2009 as a result of over ten years of research, development, and investment, thousands of HP Latex Ink systems are now employed worldwide and have printed more than 35 million square meters. HP Latex offers the versatility to cover applications including retail and outdoor advertising, event and exhibition graphics, vehicle graphics and interior decoration. The water-based formulation of HP Latex Inks meets high environmental standards that improve the work environment and meet customers’ environmental objectives for indoor displays and wall coverings.

HP Latex proprietary technology makes it possible to obtain high quality at production speeds at no extra cost compared to solvent printing technology. Versatility of media, including coated and uncoated substrates deliver odourless prints and do not require ventilation, moving the industry to healthier printing. The smooth, flexible ink layer is ideal for stretching and framing canvases. User replaceable printheads maintain image quality over the life of the printer. Scalable printhead technology enables a range of products with speeds ideal for low to medium volume printing. Delivery times are shortened; prints come out completely dry, and can be laminated immediately. Maintenance is reduced with HP water-based Latex Inks, which do not require daily manual cleaning and printers can be turned off overnight, on weekends, or longer. The HP Latex 300 Series printers are third generation technology.

HP Latex Ink Cartridges feature built-in electronic intelligence that communicates ink colour, remaining ink quantity and other information for the printer. HP Latex Inks are water-based inks that combine the best characteristics of solvent inks and water-based inks. Water give HP Latex inks the high surface tension, low viscosity and energetic vapour bubble that are ideal for use in thermal HP inkjet printheads. Composed of more than 60% water, HP Latex Inks offer important benefits to commercial and industrial production environments – water produces no VOCs (volatile organic compounds), requires no special handling, and is non-toxic, non-flammable and non-combustible. Humectants, wetting agents and additives are used to obtain required performance characteristics for an ink.

The HP Latex 335 Printer features a print zone, located on the printer platen under the scanning carriage. Here heaters evaporate some of the water, allowing the concentrated humectants and wetting agents to soften the surface of uncoated vinyl for better adhesion of the colourant layer. Remaining liquids in the ink film are evaporated by curing zone dryers to produce a completely dry and odourless print that can be immediately handled, stored, shipped or displayed indoors. The HP Optimizer interacts with HP Latex Inks to rapidly immobilize pigments on the surface of the print and achieve high image quality at high productivity.

Environmental Certifications and Eco Labels Overview:

Since 1992, HP focuses on specific environment impacts through its Design for Environment (DfE) program. DfE is an engineering perspective where the environmentally related characteristics of a product, process, or facility are optimized. Together, HP’s environmental stewards and product designers consider impact on the design of every product and solution, from the smallest ink cartridges to entire data centres. HP Latex Printing Technologies provide many opportunities to reduce and recycle. Below are the certifications for the HP Latex 315 Printer, HP 831 Latex Ink Cartridges, and selected HP Media.

EL ECOLOGO Certification to UL 2801 demonstrates that HP Latex Inks meet a range of stringent criteria related to human health and environmental conditions. UL GREENGUARD GOLD Certification to UL 2818 means HP Latex products are certified to GREENGUARD standards for low chemical emissions into indoor air during product usage. HP Wall Art printed on HP PVC-free wall paper and other prints on HP PVC-free wall paper printed with HP Latex Inks meet AgBB criteria for health-related evaluation of VOC (volatile organic compounds) emissions of indoor building product. Rated A+ per emissions dans l’air interieur refers to the level of emission of volatile substances in indoor air posing health risks if inhaled. Eco Mark Certification Number 14142007 is for the HP 831 Latex Ink Cartridges, certified by the Eco mark Office of Japan Environment Association. Energy Star qualified means the HP Latex 115 Print and Cut Solution meets strict energy efficiency guidelines without sacrificing performance and are EPEAT registered. Additionally, other certifications for some medias/textiles include EN22 standards for wash ability and colourfastness and Euro Class Standard Class B4 for flame retardant and CE Mark Type II (ASTMF793) compliant for durability characteristics.

HP printing materials are designed together with HP Latex Inks and HP Latex printers provide optimal image quality, consistency, and reliability. These include HP PVC-free Wall Paper (FSC and UL GREENGUARD GOLD Certified), HP Permanent Gloss Adhesive Vinyl (REACH compliant), HP Backlit Polyester Film (recyclable), and HP Premium Satin Canvas.
