HP DesignJet T830 (36in/ 914mm) A0 MFP Large Format Printer – Scan, Print and Copy

The HP DesignJet T830 A0 Multifunction Scan and Printer, is a robust, compact A0 Wi-Fi MFP for the office and job site. Print, scan, copy and share with a 4-colour, built-in scanner.


HP DesignJet T830 Large Format Printer and Scanner A0

The HP DesignJet T830 36-in Multifunction Scan and Printer is a robust, A0 compact Wi-Fi MFP for both the office and job sites.

Print, scan, copy and share with a 4-colour, built-in scanner at an unbeatable price! The HP DesignJet T830 reinvents multifunction and is available in both A0 (36in/914mm) and A1 (24in/610mm).

This machine is ideal for architecture and construction sites, as it’s half the size of many similar multifunction printers, and its reinforced design means it’s built to last. It also enables smooth printing anywhere on site from a smartphone or tablet with HP Mobile Printing.

Get HP DesignJet quality in small-format sizes as well with the ability to print half-size documents with a 50-sheet A4/A3 input tray.

Smart scanning technology protects originals from damage when scanning and obtains precise colours.

Design Supply is an HP Authorised Partner and DesignJet Specialist. We work closely with HP to provide the best solutions available to get the job done for your business and maximise your opportunities.

With over 30 years of experience in the large format printer market, we offer expertise and knowledge in tailoring the exact solution for your specific application.


HP DesignJet T830 MFP Series demo


The HP DesignJet T830 36-in Multifunction Printer is robust and damage-resistant for offices and job sites. Compact design means the HP T830 MFP is half the size of other 36-inch Wi-Fi integrated MFPs, standing at 140.3(w) x 62.9(d) x 115.55(h)cm (55.2 x 24.8 x 45.5 in). Choose from 40/130/300ml colour and 69/300-ml HP Ink cartridges to fit print volumes and reduce down time. Built to last, an optional HP DesignJet Rugged Case is available to protect the T830 during transport and from on-site dust.

The HP T830 MFP prints 3 times faster than previous HP models, printing A1/D-size prints in 25 seconds. A single touchscreen works like a smartphone, making the T830 MFP convenient and easy to operate. Complete tasks intuitively, including printing at half scale with the automatic sheet feeder/tray. Cut waste by 50%; reduce extra work and waste of wide paper rolls. No LAN is required, so the HPT830 MFP can be moved any time or any place the Wi-Fi signal can reach with wireless connectivity.

The HP DesignJet T830 is an ideal collaboration tool for team sharing. Conveniently scan, share, print right from your smartphone or tablet. Use integrated scanning to capture and share feedback, enable archiving, and more. The printer creates its own Wi-Fi network for easy connectivity with Wi-Fif Direct. Manage scans from your mobile device with the HP AiO Printer Remote app, enabled by HP Mobile Printing.

The HP DesignJet T830 36-in Multifunction Printer includes copying, with convenient features including reduction and enlargement of 50 to 400%, up to 99 copies, and many adjustable settings including content type, lighter/darker, background noise removal, background colour removal, blue print invert, translucent media, auto de-skew, and more.

The HP DesignJet T830 36-in Multifunction Printer includes security features for both the scanner (firewall, protection against virus attack, disable usb drive, and disable network access to scan images) and the printer (disables firmware update through USB and encrypt web communications).


Use the built-in scanner to copy and distribute sketches and hand-annotated drawings to peers/partners right away. Scan, copy and share drawings immediately with the intuitively designed single touchscreen, or use HP Smart app to email contacts and post to cloud. Scan and copy up to 600 dpi with the built-in scanner, with a straight-through scan paper path for sheet and cardboard originals up to 0.8 mm (0.03 inch). Featuring a scan speed of up to 3.81 cm/sec (1.5 in/sec) in colour and 11.43 cm/sec (4.5 in/sec) in greyscale, the built-in scanner is fast and easy to use and includes 1 GB memory. Maximum scan size is 914 x 2.77m. The 4-inch touch panel is intuitive and easy to use.

The HP DesignJet T830 36-in MFP Scan and Print produces 2400 x 1200 dpi resolution and prints line drawings in 25 seconds/page or 82 A1/D prints an hour. Printing is easy with the HP DesignJet T830 MFP. Mobile printing capability features include direct print for mobile apps for iOS, Android and Chrome OS and email printing with HP ePrint and HP Smart app for iOS and Android. The HP DJ T830 MFP supports printing from most smartphones and tablets using Android and iOS. Printing paths include Windows and Mac printer drivers, Apple AirPrint, HP Print Service Plugin for Android, HP Print for Chrome app for Chrome OS. The HP DJ T830 MFP includes drivers for HP-GL/2, HP-RTL for Windows and a Raster driver for Mac and Windows. HP Click printing software and HP DesignJet Utility for Mac and Windows are included with the HP DesignJet T830.

The HP DesignJet T830 36-in MFP Scan and Print features the HP 729 printhead and four Original HP 728 inks. Bring a new level of accuracy and professionalism to your work and enjoy reliable, trouble-free printing with the single HP 729 printhead, designed and tested with Original HP 728 Vivera inks and the HP DesignJet ePrinter to provide consistent results. Intelligence built into the printhead makes Original HP supplies easy to use by continuously optimising print quality and maximising printhead life. The result – crisp text, fine line accuracy, smooth neutral grey transitions, and a range of vivid colours, even at the fastest print speeds. Interactive printing system technology includes intelligence built into Original HP printheads, cartridges and your DesignJet printer that send alerts when supplies need to be replaced, to help minimise interruptions. Count on reliable performance for time-saving, high performance over the life of the printer.

HP 728 Vivera inks use pigment matte black and dye-based colours, cyan, magenta, and yellow to produce a wide colour gamut, sharp lines and text, smooth colour transitions, and smudge-resistant prints. HP 728 ink cartridges are mounted on the printhead carriage and are easy to replace. HP 728 ink cartridges are available in 40-ml to 300-ml sizes.

There are HP media (bright white inkjet, coated, and heavyweight coated papers, and clear film) and third party media compatible with the HP DesignJet T830 36-in MFP Scan and Print. Our media specialists at Design Supply have the expertise to help you determine the best solutions for your particular printing needs.

Optional accessories available for HP DesignJet T830 36-in MFP Scan and Print include additional 36 inch spindles and to accommodate for different media usage. An HP USB 3.0 to Gigabit Adapter is also available. A Rugged Case for transport and onsite dust is also available.

Count on dependable support to create the best image possible from HP and Design Supply. For added peace of mind, HP DesignJet MFP’s feature a 24-month warranty. HP Care Pack Services, an extensive portfolio of installation and post warranty on-site support services are available to help you enhance your printing and imaging environment, protect your IT investment and grow your business. Ask us at Design Supply, and we can tailor the best solution possible for your needs.

When environmental factors are a consideration in your purchase of a large format printer, rest assured that HP incorporate a number of environmental initiatives into the design and manufacturing of HP DesignJet MFP’s, cartridge, printheads, and media, as well as the recyclability of these components. HP Eco Solutions and HP Planet Partners programmes address energy usage, recycling, and renewing issues for printers, cartridges, printheads and media. HP even provide the HP Carbon Footprint Calculator for Printing to help you evaluate the energy consumption, paper use, carbon output and associated monetary costs of your printing.


HP DesignJet T830 36-in MFP Scan and Print: F9A30B

Printhead: F9J81A

Introductory ink cartridges

Printer stand


Quick reference guide

Setup poster

Startup software

Power cord

Refeed preventers

2 year limited warranty. Warranty and support options vary by product, country and local legal requirements.

Software included:
HP Click PrintingHP DesignJet Utility for Mac and Windows
Drivers included:
HP-GL/2, HP-RTL drivers for WindowsRaster driver for Mac OS X and Windows
Mobile Printing:
Direct print for mobile apps for IOS, Android and Chrome OSEmail printing with HP ePrint and HP Smart app for iOS and Android
Printing Paths:
Windows and Mac printer drivers, Apple AirPrint, HP Print Service Plugin for Android, HP Print for Chrome app for Chrome OS
HP DesignJet 36-in Spindle: B3Q37AHP DesignJet Rugged Case: N9M07AHP USB 3.0 to Gigabit Adapter: N7P47AA
HP 729 DesignJet Printhead Replacement Kit: F9J81AHP 728 300-ml Matte Black Ink Cartridge: F9J68AHP 728 300-ml Cyan Ink Cartridge: F9K17AHP 728 300-ml Magenta Ink Cartridge: F9K16AHP 728 300-ml Yellow Ink Cartridge: F9K15AHP 728 130-ml Cyan Ink Cartridge: F9J67AHP 728 130-ml Magenta Ink Cartridge: F9J66AHP 728 130-ml Yellow Ink Cartridge: F9J65AHP 728 69-ml Matte Black Ink Cartridge: F9J64AHP 728 40-ml Cyan Ink Cartridge: F9J63AHP 728 40-ml Magenta Ink Cartridge: F9J62AHP 728 40-ml Yellow Ink Cartridge: F9J61A
Service and Support:
HP 5 year Next Business Day Onsite Support DesignJet T830 HW: U8PH4EHP 4 year Next Business Day Onsite Support DesignJet T830 HW: U8TY9EHP 3 year Next Business Day Onsite Support DesignJet T830 HW: U8PH3E

HP 2 year Next Business Day Onsite Support DesignJet T830 HW: U8TY8E

HP 2 year Post Warranty Next Business Day Onsite Support DesignJet T830 HW: U8TZ0PE

HP 1 year Post Warranty Next Business Day Onsite Support DesignJet T830 HW: U8PH5PE

HP Monthly Next Business Day Onsite Support DesignJet T830 HW: U9JW8E

HP Installation Service with Network Setup: UC744E


HP DesignJet T830 36-in Multifunction Scan and Print Datasheet

HP DesignJet T830 24-in Multifunction Scan and Print Datasheet

HP DesignJet portfolio poster 2017 brochure

HP DesignJet  help me choose mfp 2017 brochure

HP DesignJet MFP: why upgrade your large format printer brochure

HP DesignJet T- series help me choose 2018 brochure

HP Solutions for  the Construction industry brochure

HP Solutions for Defense industry brochure

HP DesignJet Rugged Case for T830, T730 datasheet

HP beware of hidden costsbrochure

HP care pack services for HP DesignJet Large Format Printers

HP how to recycle cartridges

Partner with HP for the environment 1

Partner with HP for the environment 2


For over thirty years, HP has been transforming the way design professionals in Architecture, Engineering, Construction, Geospatial and Graphics markets operate. In the late 1970’s, HP developed the first pen plotter and HP-GL graphics language, now the industry standard. In the early 1990’s, HP invented inkjet technology and applied it to DesignJet printers, making large format printing in black-and-white easy, fast and affordable. HP continued to innovate, and introduced colour, faster printing speeds, and the ability to print high resolution images and complex files in large format in the same decade. In the new millennium, faster printing speeds and sunlight-resistant UV inks were introduced, allowing Print Service Providers and Graphics Designers to create applications for both indoor and outdoor use. Photographers began to adopt HP large format printing to replace silver halide, demonstrating HP’s ability to deliver superior image quality with prints lasting up to 200 years. In 2010, with the rise of mobility and globalisation, HP launched its first generation of ePrinters with web-connectivity features and the first multifunction large format ePrinters with copying, scanning and printing in a single device. HP have shipped over 3 million DesignJet printers around the world and are the leader in the market with the widest range of large format printers for design professionals, whether single or multi-user environments.

HP DesignJet Printers feature HP thermal inkjet technology and use a number of advanced HP proprietary technologies to achieve incredible accuracy, sharpness and superior colour fidelity. HP DesignJet T830 36-in MFP Scan and Print features HP Scalable Printing (SPT), the HP 729 printhead and HP 728 Vivera inks.

HP Scalable Printing Technology (SPT) allows HP DesignJet T Series and Z Series printers to deliver higher quality at higher speeds with more ink colours. HP SPT is the result of HP’s investment of $1.4B and four years of research and development. SPT printheads were first introduced in 2005, and incorporate fluidic design and electronic control features required to meet the demands of commercial and industrial inkjet printing. HP thermal inkjet printheads are produced on a silicon wafer using SPT integrated circuit manufacturing processes customized for HP inkjet applications. SPT offers higher density circuitry that can place more electronic functionality on the printhead than was possible in previous generations of HP thermal inkjet printheads. Each SPT-based printhead incorporates electronic circuits that process input and output signals, manage power, control the drop generators and measure the printhead temperature. Ink channels, drop generator chambers and nozzles for the printheads are built tighter across the surface of the silicon wafer and the manufacturing techniques for SPT produce complete, integrated printhead structures with features that are defined and aligned together with sub-micron precision.

The HP DesignJet T830 36-in MFP Scan and Print uses the HP 729 printhead which features automatic self-maintenance and nozzle substitution routines to provide flawless image quality, lower running costs and more efficient ink usage during installation and cleaning routines. The HP 729 printhead is part of a module that integrates the HP Thermal Inkjet printheads with ink delivery systems for the four inks. HP 728 ink cartridges are mounted on the printhead carriage and scan with it across the paper. To ensure dependable and consistent image quality every time, the drop-ejection performance of every nozzle is periodically and automatically tested with an Optical Drop Detector.

The HP DesignJet T830 36-in MFP Scan and Print features HP Vivera inks with the HP 4-ink writing system, designed and engineered together to provide high quality, high reliability, optimised efficiency and a wide colour gamut. HP Vivera colour inks are aqueous dye-based, (cyan, magenta, and yellow) for the best range of colour across a range of printing materials to produce colours optimised for technical graphics and CAD applications. Precision colour-to-colour alignment in the HP729 printhead and dye-based HP728 Vivera colour inks deliver sharp colour lines and text, a wide colour gamut with smooth colour transitions. HP Vivera pigment-based black ink delivers sharp black lines and text with maximum black optical density. HP 728 inks are fast-drying and smudge-resistant and produce superior lines and text and smooth colour transitions in images, renderings and illustrations. HP 728 ink cartridges are mechanically-keyed and colour-coded to ensure they are inserted into the proper ink slot. Ink cartridges are easily removed by a simple push-to unlock/pull-to-remove motion and installed by pushing them into their slot until the lock.

HP DesignJet MFP’s are part of the HP Eco Solutions programme, aimed at energy usage, carbon footprint, recycling and environmental considerations. HP DesignJet MFP’s meet strict energy efficiency guidelines without sacrificing performance or your productivity. HP Designjet MFP’s  are ENERGY STAR compliant to help you keep your energy costs down. ENERGY STAR is a joint program of the U.S. Environmental Protection Agency (EPA) and the U.S. Department of Energy. HP also aims to make it easy for you to reduce the carbon footprint of your printing.

HP DesignJet MFP’s  are designed for recyclability. HP Planet Partners programme is for recycling your HP DesignJet ink cartridges. All HP print cartridges returned go through a multiphase recycling process where they are reduced to raw materials. These materials can then be used to make new metal and plastic parts and products. No HP print cartridges returned and recycled through HP Planet Partners are sent to landfill. Most HP DesignJet printheads can also be returned through the HP Planet Partners programme. When it’s time to upgrade or dispose of your HP DesignJet MFP, HP offers several environmentally sound options for renewing or disposing of your unwanted hardware. HP Trade-in, HP Buy-back, and HP Planet Partners recycling programmes are all viable options. Design Supply will be able to help you decide which option is best for you.
