Mutoh ValueJet 1617H large format solvent printer

The Mutoh ValueJet VJ-1617H 1625mm/ 64 inch, roll and rigid hybrid printer is Mutoh’s first printer with white inks. The ValueJet-1617H is an affordable versatile printer for the Sign & Display market. Ideal for Print Service Providers and Print Shops creating trade show graphics, POP displays, vehicle wraps, packaging prototypes, promotional products and indoor and outdoor signage, the Mutoh ValueJet VJ-1617H also meets demanding customer requirements for “green output”. The Mutoh ValueJet VJ-1617H dual functionality to print on both rigid substrates and roll media with a wide colour gamut combined with multiple application design makes it a truly versatile printer, maximising your floor space and profitability.

Compatible with both rigid and roll media, the Mutoh ValueJet VJ-1617H Printer producing high quality graphics for short viewing distances including Trade Show Graphics, POP, Customised Interior Decoration, Small Lot Packaging Prototypes, Banners, Posters and more. The ValueJet VJ-1617H is compatible with Mutoh’s MP11 Multi Purpose renewable resource inks, offering print compatibility with a unique range of substrates. The MP11 CMYK White inks are non-petrochemical based and can print on recyclable media.

Design Supply, a Mutoh Authorised Reseller, works closely with Mutoh to provide the best solutions available to get the job done for your business and maximize your opportunities. With more than 26 years of experience in the large format printer market, Design Supply offers expertise and knowledge in tailoring the exact solution for your specific application.

SKU: VJ-1617H Category: Large Format Discontinued Tag: No Lease

Mutoh

Description

Market and Applications

The ValueJet VJ-1617H offers a wide range of print modes and speeds. .

Print Mode	Resolution dpi	Speed m²/hr	Speed m²/hr	Speed m²/hr	Speed m²/hr
		4-colour setup:	5-colour setup	5-colour setup White only	5-colour setup CMYK W
		2 x CMYK	CMYK only
High Quality	720 x 1080	3.4	1.4	3.4	0.4
Quality	720 x 1080	6.71	3.06	6.71	1
High Quality	720 x 720	5	2.4	5	0.76
Quality	720 x 720	10.1	4.75	10.1	1.76
High Quality	720 x 540	3.25	3.25	3.25	1.12
Quality	720 x 540	6.5	6.5	6.5	2.5

Intelligent design features make the ValueJet VJ-1617H easy to set up and operate. The ValueJet VJ-1617H comes with a stand and integrated front and rear roller tables. The ValueJet VJ-1617H can accommodate rigid materials up to 15mm thick with a maximum weight of 15kg. Automatic media thickness detection is measured electronically and head height is adjusted automatically, simplifying set up and changes in media.

The ValueJet VJ-1617H features an integrated full width 64″ Air Knife Media Drying System which ensures output is dry straight from the printer. The air knife delivers instant heat from the top allowing quick drying of roll and rigid prints. A range of surface temperatures of up to 50C enable wide substrate compatibility.

Optional items for the ValueJet VJ-1617H Printer include Media Transport Tables, Motorised Torque Take up Systems, SpectroVue VM-10 specrophotometer, and ValueCut Systems. The Media Transport Tables included three arms with an integrated roller ball system to feed rigid and semi-rigid media into the printer. The Take-up Systems are designed for roll to roll productivity.

Directly attachable to the print head carriage or shuttle of the printer, the SpectroVue VM-10allows monitoring of colour drift over time, from job-to-job or even within a large job. The VM-10 can also be used to build ICC colour profiles and linearization files, in combination with supporting software. The VM-10 allows fast, simple and accurate colour measuring and process control to your workflow, producing consistent colour prints every time with the on-board ColorVerify system. The ValueCut Systems are designed for ultimate productivity for cutting output.

Built to last, Mutoh ValueJets are renowned for precision engineering and meticulous production practices for years of profitable use. As you would expect from Mutoh, reliable performance is a given. For added peace of mind, Mutoh ValueJet printers feature a 12-month on-site warranty.

There is a complete range of Mutoh and third party media, compatible with the ValueJet VJ-1617H, available from Design Supply’s media specialists whose expertise can help you determine the best solutions for your particular printing needs.

Downloadable Mutoh ValueJet 1617H Brochures
Mutoh ValueJet VJ-1617H	Mutoh MP11 Multi Purpose inks specifications here	Mutoh Print Inspiration	Mutoh Onyx 12 RIPCenter ValuePlus Mutoh Edition RIP software
Mutoh SAi FlexiPRINT SE12 Mutoh Edition RIP	Mutoh SpectroVue VM-10 brochure	Mutoh ColorVerify System brochure	Mutoh ValueCut brochure
Mutoh ValueCut specifications	Mutoh’s white paper on How green is green	Mutoh Torque Take Up Systems	Mutoh Take Up Systems

VIDEOS

Mutoh VJ-1617H

Mutoh Intelligent Interweave Technology

See how Mutoh printers are manufactured

KEY FEATURES

Designed for a wide variety of roll and rigid media, the Mutoh ValueJet VJ-1617H delivers excellent print quality on uncoated polyester, PP, PE, ABS, PET, PMMA, non-pvc self-adhesive media, uncoated Tyvek, cardboard, recyclable fibre-based paper, PVC foam board, aluminium sandwichboard, and more. The ValueJet VJ-1617H can be used for both car wraps and rigid substrates with equal ease. It prints directly onto corrugated plastics, polystyrene, banner material, vinyl and wall coverings, as well as roll surfaces with a wide colour gamut. .

Featuring drop-on-demand micro piezo inkjet single print head and Mutoh’s award-winning Intelligent Interweaving print technology, the ValueJet VJ-1617H produces vibrant and crisp colours, flawless solid colours and unrivalled smooth gradations. Maximise your profit with Mutoh’s award-winning Intelligent Interweaving print technology, which offers predictable and repeatable output quality fit for purpose every time in the shortest possible time. Intelligent interweaving drastically reduces or even eliminates horizontal banding, step mismatch banding and the visible effects of missing or misfiring nozzles.

The Mutoh ValueJet VJ-1617H Printer is designed for use with Mutoh MP11 Multi-Purpose renewable resource Inks available in C, M, Y, and K and white. Mutoh MP11 inks are UV alternative bio-based inks which create high quality prints on both rigid and roll substrates, suitable for outdoor and indoor applications and offer UV durability without lamination for up to three years outdoor. In case mechanical stress is involved, lamination is required and stabilisation is required prior to lamination. Mutoh MP11 inks are available in 950ml (CMYK) and 500ml (white). The average ink consumption is 8ml/m² at 720 dpi with 67% coverage for graphics. Suited for both high quality and high speed printing, Mutoh UMS inks also require minimal printer maintenance and are fixed and dried at regular heating temperatures.

The ValueJet VJ-1617H is ideal for start-up companies and established print businesses wanting short run production of roll prints and panel creation for close viewing distances. It is the versatile and economic option that reduces impact on the environment.

MORE INFORMATION

More information on Mutoh proprietary technologies

Mutoh has been at the forefront of the wide format industry for more than 20 years. As an innovative developer and manufacturer of wide-format printers and cutters, Mutoh incorporates pioneering technology to bring you the best equipment for your application. The range of Mutoh ValueJet printers features best-in-class inkjet head technology, latest generation electronics and high quality inks.

Mutoh’s new wide piezo drop-on-demand print head features 1440 nozzles. The 1440 nozzle head includes four colour sections (C, M, Y, K) each divided in two nozzle rows with 180 nozzles per colour. Because all colour head sections are united in one head, there is no need for time consuming head-to-head calibration routines. The print head is capable of producing ink drops ranging from 3.6 picoliters to 15.5 picoliters, resulting in incredible accuracy, sharpness, and speed. Increased accuracy and consistency of dot size and dot release during printing improves the image, in addition to increased dot gain control, allowing for more latitude in profile settings.

Mutoh’s award-winning Intelligent Interweaving print technology drastically reduces or totally eliminates the typical difficulties inherent to conventional digital inkjet printing, including defects such as horizontal banding, ink mottle, bleed and the visible effects of missing or misfiring nozzles. Ink is laid down in waves, as opposed to straight lines used on most wide format printers. The biggest benefit of this proprietary Mutoh print technology is that it offers predictable and repeatable output quality, bringing an unprecedented level of user comfort to the printer operator.
