Hewlett Packard HP Designjet Z5200 PS Large Format Printer

SKU: CQ113A Category:


Market and Applications and who uses this type of large format printer

When professional fast printing with intelligent workflow and easy, unattended and reliable operation are important, the HP DesignJet Z5200 PostScript Printer is ideal.   The HP DesignJet Z5200 Postscript Printer, an 8-colour, 44 inch/B0, 300ml ink capacity large format printer is designed for Copy Shop, Graphic Design, Professional Photography, Fine Art, Retail, CAD & GIS, and Print Service Provider (PSP) markets.  Achieve high-quality, high-impact, long-lasting colour prints from a wide range of applications with built-in PostScript support for PS/PDF files.

Ideal for large format printing in multiple applications, the HP DesignJet Z5200 creates high-quality, prints and concept proofs with accurate and consistent colours on canvas and other speciality media including photo, fine arts, proofing, bond and coated papers; backlit, self-adhesive, banner, sign and fine art printing materials; films; and textiles and fabrics.

At Design Supply, a Designjet Graphics Specialist and HP Gold Partner, we work closely with HP to provide the best solutions available to get the job done for your business and maximize your opportunities.  With over 27 years of experience in the large format printer market, we offer expertise and knowledge in tailoring the exact solution for your specific application.

The HP DesignJet Z5200 PostScript Printer produces up to 2400 x 1200 dpi resolution and has a maximum print speed of 41m²/hr and production speed of 9m²/hr without sacrificing quality. The HP DesignJet Z5200 features 32GB virtual memory and a 160GB hard disk to help you streamline your workflow and process large files quickly and easily.

Drivers included with the HP DesignJet Z5200 PostScript Printer include HP PCL3 GUI and PostScript® drivers for Windows® (optimised for AutoCAD 2000 and higher) and Mac® OS X.  There is also support for Citrix® XenApp and Citrix® CenServer environments.  Media can be fed via the sheet feed or roll feed and the automatic cutter cuts all media except canvas. Print unattended, using convenient snap-in, snap-out 300ml HP ink cartridges, Track your printing business by costs, job or customer with HP Designjet Excel Accounting Report.

Get cost-effective everyday printing and enhanced print quality with HP Universal Bond Paper and HP Bright White Inkjet Paper featuring ColorPRO Technology. Our media specialists at Design Supply have the expertise to help you determine the best solutions for your particular printing needs.

Optional accessories for the HP DesignJet Z5200 include an additional 44 inch spindle to accommodate for different media usage, such as technical paper and photographic paper, conveniently ready to load.

Count on dependable support to create the best image possible from HP and Design Supply.  For added peace of mind, HP DesignJet printers feature a 12-month warranty.  HP Care Pack Services, an extensive portfolio of installation and post warranty on-site support services are available to help you enhance your printing and imaging environment, protect your IT investment and grow your business. Ask us at Design Supply, and we can tailor the best solution possible for your needs.

If environmental factors are a consideration in your purchase of a large format printer, rest assured that HP incorporate a number of environmental initiatives into the design and manufacturing of HP DesignJet printers, cartridge, printheads, and media, as well as the recyclability of these components.  HP Eco Solutions and HP Planet Partners programmes address energy usage, recycling, and renewing issues for printers, cartridges, printheads and media. HP even provide the HP Carbon Footprint Calculator for Printing to help you evaluate the energy consumption, paper use, carbon output and associated monetary costs of your printing.

Downloadable HP DesignJet T-Series Brochures


Key features of the HP DesignJet Z5200 PostScript Printer

The HP DesignJet Z5200 PostScript Printer features HP thermal inkjet technology with 8 HP Vivera Photo inks including the HP Three-Black Ink set.  Create prints with or without borders on a range of HP creative and speciality media that resist fading for up to 200 years.

Get breakthrough colour results thanks to the first-ever embedded spectrophotometer.  This precision tool enables automatic advanced colour calibration and easy ICC profiling, minimising expensive trial-and-error printing.  Meet customers’ colour expectations quickly and reliably with HP Professional Pantone® emulation and create a customised Pantone® simulation swatchbook.

HP Instant Printing Pro streamlines the printing process from beginning to end, with fast, easy file preparation, automatic nesting, preview, orientation and crop marks. Save half the steps needed to create a print using HP Instant Printing Pro versus printing from an application using the driver.  Submit many files at a time, directly to the HP Z5200, without having to wait to open an application.


More information on HP DesignJet proprietary technologies

For over thirty years, HP has been transforming the way design professionals in Architecture, Engineering, Construction, Geospatial and Graphics markets operate. In the late 1970’s, HP developed the first pen plotter and HP-GL graphics language, now the industry standard. In the early 1990’s, HP invented inkjet technology and applied it to DesignJet printers, making large format printing in black-and-white easy, fast and affordable. HP continued to innovate, and introduced colour, faster printing speeds, and the ability to print high resolution images and complex files in large format in the same decade. In the new millennium, faster printing speeds and sunlight-resistant UV inks were introduced, allowing Print Service Providers and Graphics Designers to create applications for both indoor and outdoor use. Photographers began to adopt HP large format printing to replace silver halide, demonstrating HP’s ability to deliver superior image quality with prints lasting up to 200 years. In 2010, with the rise of mobility and globalisation, HP launched its first generation of ePrinters, with web-connectivity features and the first multifunction large format ePrinters with copying, scanning and printing in a single device. HP have shipped over 3 million DesignJet printers around the world and are the leader in the market with the widest range of large format printers for design professionals, whether single or multi-user environments.

The HP DesignJet Z5200 PostScript Printer features HP thermal inkjet technology and use a number of advanced HP proprietary technologies to achieve incredible accuracy, sharpness and superior colour fidelity, water-resistant prints that resist fading for more than 200 years on a range of HP media (interior display, away from direct sunlight). The HP DesignJet Z5200 PostScript Printer features an embedded spectrophotometer, HP Scalable Printing (SPT) and HP Electrosteric Encapsulation (EET) technologies and HP Vivera aqueous pigment inks.

The embedded i1 spectrophotometer from X-Rite in the HP Z5200 makes calibration and profiling simple. Close collaboration between HP and X-Rite ensures a reliable solution that has been thoroughly tested to meet customer demands for ease, quality, and dependability. .

HP Scalable Printing Technology (SPT) allows HP DesignJet Z Series and T Series printers to deliver higher quality at higher speeds with more ink colours. HP SPT is the result of HP’s investment of $1.4B and four years of research and development. SPT printheads were first introduced in 2005, and incorporate fluidic design and electronic control features required to meet the demands of commercial and industrial inkjet printing. HP thermal inkjet printheads are produced on a silicon wafer using SPT integrated circuit manufacturing processes customized for HP inkjet applications. SPT offers higher density circuitry that can place more electronic functionality on the printhead than was possible in previous generations of HP thermal inkjet printheads. Each SPT-based printhead incorporates electronic circuits that process input and output signals, manage power, control the drop generators and measure the printhead temperature. Ink channels, drop generator chambers and nozzles for the printheads are built tighter across the surface of the silicon wafer and the manufacturing techniques for SPT produce complete, integrated printhead structures with features that are defined and aligned together with sub-micron precision. HP thermal inkjet printheads feature a modular snap-out/snap-in design for simple and quick user replacement. HP’s Z5200 PostScript Printers print a test plot whenever a printhead is replaced, and the plot is automatically scanned by an optical sensor on the print carriage to perform an automatic colour-to-colour alignment without requiring manual mechanical adjustments.

The HP DesignJet Z5200 PostScript Printer uses long-lasting HP 70 printheads which feature automatic self-maintenance and nozzle substitution routines to provide flawless image quality, lower running costs andmore efficient ink usage during installation and cleaning routines. The four user-replaceable printheads contain two colours per printhead with 2112 nozzles each, or 1056 nozzles per colour. The ink drop size ranges from 4 picoliter (light cyan, light magenta, light grey and photo black) to 6 picoliter (cyan, magenta, yellow and matte black). To ensure dependable and consistent image quality every time, the drop-ejection performance of every nozzle is periodically and automatically tested with an Optical Drop Detector.

The HP DesignJet Z5200 PostScript Printer features HP Vivera Photo inks with the HP 8-ink writing system, designed and engineered together to provide optimised efficiency and a wide colour gamut. HP Vivera Photo inks are aqueous, pigment-based inks which include five colours: cyan, magenta, yellow, light cyan, light magenta, and the HP Three-Black Ink set: photo black, matte black and light grey. The two black inks, photo (pK) for photo media with glossy and satin finish and matte (mK) for matte media such as fine art paper combined with the light grey ink, significantly reduce image grain, metamerism (greys appear green under fluorescent lighting), and provide accurate reproduction of neutral grey tones from white to black. The HP Three-Black Ink set prints true neutral greys and rich, dark blacks whether using matte or glossy papers, without wasting time and money swapping ink cartridges. HP Vivera Photo inks produce water-resistant prints that resist fading for more than 200 years on a range of HP media (interior display away from direct sunlight).

HP Vivera pigment inks use HP Electrosteric Encapsulation Technology (EET) to surround each pigment particle with an electrically-charged polymer (“resin”) coating. When the ink vehicle is absorbed by or evaporated from the print medium, the resin encapsulates the pigment and forms a durable colourant film on the surface. EET creates stable dispersion of pigments in ink to increase shelf and service life and improves inkjet-ability, and helps prevent pigment coalescence on the print surface and improves image quality.

ColorPRO Technology is a licensing programme for a wider range of media products, technologies and applications. ColorPRO Technology was originally designed for uncoated papers containing proprietary surface-treatment chemistry resulting in bolder blacks, brighter colours and sharper lines when printed with aqueous–pigment based inks, ColorPro now includes coated papers, textiles, and films for large format printing applications. Papers and media with ColorPRO Technology perform to a strict set of specifications to meet industry–leading performance standards The specific technology behind media with ColorPRO Technology varies from product to product, however all products with ColorPRO Technology utilise advanced technologies which have been designed together with Original HP inks and HP printers to optimise printing system performance.

HP DesignJet printers are part of the HP Eco Solutions programme, aimed at energy usage, carbon footprint, recycling and environmental considerations. HP Designjet printers meet strict energy efficiency guidelines without sacrificing performance or your productivity. HP Designjet printers are ENERGY STAR® compliant to help you keep your energy costs down. ENERGY STAR is a joint program of the U.S. Environmental Protection Agency (EPA) and the U.S. Department of Energy. HP also aims to make it easy for you to reduce the carbon footprint of your printing.

HP DesignJet printers are designed for recyclability. HP Planet Partners programme is for recycling your HP DesignJet ink cartridges. All HP print cartridges returned go through a multiphase recycling process where they are reduced to raw materials. These materials can then be used to make new metal and plastic parts and products. No HP print cartridges returned and recycled through HP Planet Partners are sent to landfill. Most HP DesignJet printheads can also be returned through the HP Planet Partners programme. When it’s time to upgrade or dispose of your HP DesignJet printer, HP offers several environmentally sound options for renewing or disposing of your unwanted hardware. HP Trade-in, HP Buy-back, and HP Planet Partners recycling programmes are all viable options. Design Supply will be able to help you decide which option is best for you.

Downloadable HP Designjet Z5200 PS Large Format Printer Brochures



  • HP DesignJet T2500 Multifunction Printer: CR358A; HP DesignJet T2500 914mm PostScript Multifunction Printer: CR359A
  • Printhead
  • Introductory ink cartridges
  • Stacking tray
  • Printer stand and media Bin
  • Spindles
  • Quick reference guide
  • Setup poster
  • Power cord
  • 1 year limited warranty. Warranty and support options vary by product, country and local legal requirements.

Software included:

  • HP DesignJet ePrint & Share for Windows,
  • HP Instant Printing PRO for Windows,
  • HP Printer Utility for Mac and Windows


  • HP DesignJet T9x0/Tx500-36-in Spindle: COE65A
  • HP DesignJet 3-in Core Adapter: CN538A


  • HP 727 DesignJet Printhead B3P06A
  • HP 727 40-ml Photo Black Ink Cartridge: B3P17A
  • HP 727 40-ml Cyan Ink Cartridge: B3P13A
  • HP 727 40-ml Magenta Ink Cartridge: B3P14A
  • HP 727 40-ml Yellow Ink Cartridge: B3P15A
  • HP 727 40-ml Grey Ink Cartridge: B3P18A
  • HP 727 69-ml Matte Black Ink Cartridge: C1Q11A
  • HP 727 130-ml Photo Black Ink Cartridge: B3P23A
  • HP 727 130-ml Cyan Ink Cartridge: B3P19A
  • HP 727 130-ml Magenta Ink Cartridge: B3P20A
  • HP 727 130-ml Yellow Ink Cartridge: B3P21A
  • HP 727 130-ml Grey Ink Cartridge: B3P24A
  • HP 727 130-ml Matte Black Ink Cartridge: B3P22A
  • HP 727 300-ml Matte Black Ink Cartridge: C1Q12A
Downloadable HP Designjet T2500 MFP Brochures

Service and Support:

  • HP 5 year Next Business Day DesignJet T2500 36-inch MFP Hardware Support:U0ME2E
  • HP 4 year Next Business Day DesignJet T2500 36-inch MFP Hardware Support:U0ME1E
  • HP 3 year Next Business Day DesignJet T2500 36-inch MFP Hardware Support:U0MD9E
  • HP 3 year 4-hour 9×5 DesignJet T2500 36-inch MFP Hardware Support:U0ME3E
  • HP 2 year Post Warranty Next Business Day DesignJet T2500 36-inch MFP Hardware Support:U0MF1PE
  • HP 1 year Post Warranty Next Business Day DesignJet T2500 36-inch MFP Hardware Support:U0ME9PE
  • HP 1 year Post Warranty 4-hour 9×5 DesignJet T2500 36-inch MFP Hardware Support:U0MF2PE
DS HP Care Pack Services
